Power Management System

The VS15 display complies with the VESA DPMS standard. This standard provides
four power-saving modes, based on the display detecting the horizontal or vertical
sync signal. This table describes the four modes.

When the display is in power-saving mode, or when it detects an incorrect timing,
the display screen goes blank and the power LED indicator blinks.

Mode

AC Input Power
(including AC adapter)

LED Status

ON

with audio

without audio

40 watts maximum

37 watts maximum

Steady green

Steady green

Standby

5 watts maximum

Blinking green

Suspend

5 watts maximum

Blinking green

OFF

5 watts maximum

OFF
