Resistive-touch display

MORE

VS15XAD-TR Display

Part Number

VS15XAD-TR 15-inch XGA Medically Certified Display with desk
stand and US power cord (resistive touch)

996-0476-00

VS15XAD-TR 15-inch XGA Medically Certified Display with desk
stand and European power cord (resistive touch)

996-0476-01

VS15XAD-TR 15-inch XGA Medically Certified Display with
universal mounting plate and US power cord (resistive touch)

996-0476-02

VS15XAD-TR 15-inch XGA Medically Certified Display with
universal mounting plate and European power cord
(resistive touch)

996-0476-03

Cable & Power Adapter

Part Number

Touchscreen cable, 2 m, white, smooth surface

903-0233-00

Power adapter, Ault

903-0013-01
