Technical

Information

VS15XAD/VS15XAD-TR

Specification

Display panel

381 mm (15-in.) XGA active-matrix color TFT LCD

Display color

262,144 colors

Dimension (mm)

408 x 333 x 85 (W x H x D)

Weight (kg)

5 kg

Display area (mm)

304.1 x 228.1 (W x H); 380.1 mm (15-in.) diagonal

Response time (ms)

30 ms ON and 25 ms OFF maximum

Viewing angle

±80 degrees typical (horizontal or vertical)

Contrast ratio

400:1 typical

Brightness

Non-touch

Resistive touch

228 cd/m

2

typical

200 cd/m

2

typical

Pixel pitch (mm)

0.297 (W) x 0.297 (H)

Reliability

Monitor

Backlight

40,000 hours mean time between failure (MTBF)
50,000 hours to reach 50% of initial brightness

Video interface

15.4 M, 8 bit

Scanning frequency

Analog

Digital

Horizontal: 24 to 62 kHz; Vertical: 50 to 90 Hz
Horizontal: 30 to 64 kHz; Vertical: 56 to 85 Hz

Power consumption

40 watts maximum; <5 watts in standby or off mode

Power adapter, Ault

Input power

12 volts / 3.5 amps, 40 watts
100 volts AC to 240 volts AC at 50 to 60 Hz, AC Adapter (external)

Audio

Stereo speakers
Maximum input levels
Input impedance

1 watt amplifier
1 volt RMS typical
2000 ohms typical

Stereo headphone jack output

Output power

1 watt at 8 ohms

Temperature

Operating

Nonoperating

0° to 40° C
-20° to 65° C

Humidity

Operating

Nonoperating

10% to 93% relative humidity noncondensing
0% to 95% relative humidity noncondensing

Altitude

Operating

Nonoperating

0 to 3500 m
0 to 1220 m

Shock

50 g, 11 ms duration operating/nonoperating
(Half sine with three shocks on each of six axes)

Regulatory

See

Regulatory Compliance
