Page 57

VQT3Q78

When recording, the input level from the built-in microphones and the external microphone
terminal can be adjusted.
≥ Change the mode to

≥ Set the iA/MANUAL/FOCUS switch to manual mode. (

l 63)

Select the menu.

(When [SETr

]/[SET] is selected)

Adjust the microphone input level
using the cursor button right or left.

≥ Select

using the cursor button and press

the cursor button in the center to activate/
disactivate AGC. When AGC is activated, the
icon is surrounded by yellow and the amount
of sound distortion can be reduced. When
AGC is disactivated, natural recording can be
performed.

≥ Adjust the microphone input level so that the

last 2 bars of the gain value are not red.
(Otherwise, the sound is distorted.) Select a lower setting for microphone input level.

Select [ENTER] using the cursor button and press the button in the center to
determine the microphone input level, then select [EXIT] and press the
button in the center.

≥

(Microphone input level meter) is displayed on the screen.

≥ When changing to intelligent auto mode, the setting is fixed to [AUTO] and cannot be

changed.

≥ When [ZOOM MIC] is [ON], the volume will be different depending on the zoom rate.
≥ The microphone input level meter shows the larger of the inputs from the microphones.
≥ You cannot record with the audio completely muted.

[MIC LEVEL]

: [RECORD SETUP]

# [MIC LEVEL] # desired setting

[AUTO]:

AGC is activated, and the recording level is adjusted
automatically.

[SETr

]/[SET]:

The desired recording level can be set.

A Left
B Right
C Microphone input level
