SNMP MIB Objects
E-30 3160-A2-GB21-80 March 1999
Table E-1. SNMP MIB to Front Panel Command Cross-Reference (2 of 4)
Front Panel Command SNMP MIB Object
Stat–>Tstat:
LLB Test Active
PLB Test Active
RLB Test Active
DLB Test Active
DCLB on Port
n
DTLB on Port n
1–8 Test Active
QRSS Test Active
QRSS on Port
n
511 on Port n
Monitoring QRSS
Mon QRSS, Port
n
Mon511, Port n
Read:
dsx1LineLoop from dsx1LoopbackConfig for Net T1
dsx1PayloadLoop from dsx1LoopbackConfig for Net
T1
dsx1PayloadLoop from dsx1LoopbackConfig for DTE
T1
dsx1LineLoop from dsx1LoopbackConfig for DTE T1
testFullDuplexLoopback from IfExtnsTestType for Port
n
testLoopDTLB from IfExtnsTestType for Port n
dsx1SendOtherTestPattern from dsx1SendCode for
Net T1
dsx1SendQRS from dsx1SendCode for Net T1
testSendQRSS from IfExtnsTestType for Port n
testSend511 from IfExtnsTestType for Port n
testMonQRSS from ifExtnsTestType for Net T1
testMonQRSS from ifExtnsTestType for Port n
testMon511 from ifExtnsTestType for Port n
Stat–>LED–>Prtn:
DTR
CTS
RTS
Read:
rs232InSigState from rs232InSigName == dtr
rs232outSigState from rs232OutSigName == ctr
rs232InSigState from rs232InSigName == rts
Stat–>ID:
Ser
Mod
SRev
HRevCCA1
HRevCCA2
Read the sysDescr object from the System Group
Test–>Rlpbk–>LLBUP Set dsx1SendCode to dsx1SendLineCode
Test–>Rlpbk–>LLBDN Set dsx1SendCode to dsx1SendResetCode
Test–>Rlpbk–>54UP–>Prt n Set IfExtnsTestType for port n to testSendV54Up
Test–>Rlpbk–>54DN–>Prt n Set IfExtnsTestType for port n to testSendV54Down
Test–>Rlpbk–>FT1UP–>Prt n Set IfExtnsTestType for port n to testSendFT1UP
Test–>Rlpbk–>FT1DN–>Prt n Set IfExtnsTestType for port n to testSendFT1Down
Test–>Lpbk–>LLB
Test–>Lpbk–>Abort–>LLB
Set dsx1LoopbackConfig for Net T1 to dsx1LineLoop
Set dsx1LoopbackConfig for Net T1 to dsx1NoLoop
Test–>Lpbk–>PLB
Test–>Lpbk–>Abort–>PLB
Set dsx1LoopbackConfig for Net T1 to
dsx1PayloadLoop
Set dsx1LoopbackConfig for Net T1 to dsx1NoLoop
