Operating Instructions
18
2.2 Network Camera Configuration Type
Network Camera can be connected over the LAN/Intranet and the Internet. Select
from the four Network Camera configuration types. Network parameters differ
depending on the Network Camera configuration type.
[Type 1]—LAN/Intranet Connection with an Ethernet
Switching Hub
Network Camera can be installed on the LAN/Intranet.
* 1 Network traffic can be improved by using the Ethernet switching hub.
[Type 2]—Internet Connection with a Broadband Router
Network Camera can be accessed from the Internet. The broadband router needs
Port Forwarding (IP Masquerade) feature on page 32.
LAN/Intranet
Ethernet switching hub * 1
Modem
Broadband
Router
CATV
xDSL
Optical cable
Internet
WAN LAN
