To confirm
On-hook.
Display PT
Confirm the Timed Reminder
information.
C.Tone
Off-hook.
2
Dial extension number
or press desired DSS.
OR
extension no.
(DSS)
Enter 76 . Enter 2.
7 6
1234 11:50 AM Onetime
Enter Room Number
• When a timed reminder starts, and when it is answered or not answered, detailed timed re-
minder information is recorded automatically. This requires system programming.
Date Time Ext CO Dial Number
02:45PM
02:46PM
02:47PM
1234
1234
1234
Timed Reminder/Start
Timed Reminder/No Answer
Timed Reminder/Answer
02/02/00
02/02/00
02/02/00
• Users of PTs without displays can confirm only whether a timed reminder has been set or not
by following the steps shown above. If set, a confirmation tone will be heard.
• For information about other Hospitality features, refer to "1.3.33 HOSPITALITY FEA-
TURES".
1.3.74 Walking COS
You can use your calling privileges (Class of Service) at another extension. You can override restrictions which
have been set at that extension. To use this feature, an original extension number and an extension PIN
(Personal Identification Number) are required.
After performing the Walking COS feature, you can set the following features on your telephone from another
extension or through DISA.
• Call Forwarding (FWD)/Do Not Disturb (DND)
• Changing the Log-in/Log-out Status of Extensions
• Absent Message
• Extension Dial Lock
• Time Service—Changing the Time Mode (Day/Night/Lunch/Break)
140 Operating Manual Document Version 2008-09
1.3.74 Walking COS
