CQ-VD7001U

Settings

(continued)

English

[MENU]

[MODE]

[]] [[] [}] [{]

[ENTER]

: Previous menu

: Quit

: Select/adjust

: Determine

[MENU]

[MODE]

[]] [[] [}] [{]

[ENTER]

: Previous menu

: Quit

: Select/adjust

: Determine

LPF/HPF

(Low Pass Filter/High Pass Filter)

Cut off frequency

: down,

: up

Setting range:

(in 5 Hz step)

default:

: down,

: up

Setting range:

(in 5 Hz step)

default:

Note:
¡This setting is not available if

(SRS setting) is

set to

(on).

(High pass filter) is enabled only on the

front speakers (R/L) and rear speakers (L/R).

HPF CUT OFF

CS Auto

OFF

225 Hz

90 Hz

OFF

[

]

(High Pass Filter)

HPF CUT OFF

100 Hz

160 Hz

60 Hz

[

]

(Sub-woofer Low Pass Filter)

LPF CUT OFF

SP LEVEL

(Speaker level)

Adjusting the output balance of each speaker

: down,

: up

: down,

: up

: down,

: up

: down,

: up

: down,

: up

: down,

: up

Setting range: –10 dB to +10 dB (1 dB steps)

Default: ± 0 dB for all speakers

A test signal (a continuous tone) is output from each
speaker for approximately 2 seconds.
Adjust the output balance so that the tone appears to have
the same volume from each speaker.
Adjusting the output balance:
Adjust the volume of all of the other speakers to the volume
level of the speaker from which the test signal appears to be
the quietest.
¡If the speaker setting is

(none) or

(no) for a

speaker, the test signal is not output and that speaker
cannot be selected.

¡Turn rotary volume controller or press [}] or [{]

(

VOL) to adjust the volume of the test signal.

NONE

[

]

(Subwoofer speaker output bal-
ance)

SUB - W

[

]

(Left surround speaker output
balance)

SURROUND

[

]

(Right surround speaker output
balance)

SURROUND

[

]

(Right front speaker output bal-
ance)

FRONT R

[

]

(Center speaker output balance)

CENTER

[

]

(Left front speaker output bal-
ance)

FRONT L

SP SETUP

(Speaker set up)

Setting the absence/presence and size of each speaker

: for large speakers, when bass playback is

possible (at least 100 Hz or lower)

: for small speakers, or when bass playback is

not possible

default:

LARGE

SMALL

LARGE

(Front speaker setting)

FRONT

: when using a subwoofer

: when not using a subwoofer

default:

* A subwoofer (option, CJ-HD302 recommended) is

required. A power amplifier (option) is also required for
connecting a subwoofer.

YES

(Subwoofer speaker setting)

SUB - W

: for large speakers, when bass playback is

possible (at least 100 Hz or lower)

: for small speakers, or when bass playback is

not possible

: when not using a center speaker

default:

* A center speaker (option, EAB-CF2 recommended) is

required.

NONE

SMALL

LARGE

(Center speaker setting)

CENTER

: for large speakers, when bass playback is

possible (at least 100 Hz or lower)

: for small speakers, or when bass playback is

not possible

: when not using a surround speaker

default:

LARGE

NONE

SMALL

LARGE

(Surround speaker setting)

SURROUND

(AUDIO continued)

Note:
¡While the private mode is active, only

can be

adjusted.

FRONT

Note:
¡While the private

mode is active, only

and
can be

adjusted.

FRONT R

FRONT L

SP DELAY

(Speaker delay)

Adjusting the timing with which the audio from each speak-
er reaches the listener’s position

: down,

: up

Setting range: 0 ms to 5 ms (1 ms steps)

1 ms = 0.001 seconds

default: 0 ms

: down,

: up

Setting range: 0 ms to 15 ms (1 ms steps)

1 ms = 0.001 seconds

default: 0 ms

¡Make this adjustment while listening to sound.
¡If the speaker setting is

(none)

for a speaker, that

speaker cannot be selected.

¡When “PRO LOGIC” is displayed, 15 ms are automatically

added to the delay time setting for the surround speakers.

NONE

[

]

(Surround speaker delay time
setting)

SURROUND

[

]

(Center speaker delay time set-

ting)

CENTER

MODE LEVEL

Setting the VTR/AUX input level

Make this setting if it is not possible to adjust the volume
through the connected device (on the output side).

: sets the level low/sound volume increases

: sets the level high/sound volume decreases

default:

: sets the level low/sound volume increases

: sets the level high/sound volume decreases

Note:
¡If the input level from VTR/AUX is too high, the audio will

not be output normally.

¡After setting the input level

The volume can be adjusted by pressing [}] or [{]
(VOL) on the remote control or turning rotary volume
controller on the unit.

default:

HIGH

LOW

(Setting for AUX)

AUX LEVEL

HIGH

LOW

(Setting for VTR)

VTR LEVEL
