Timing Mode Table
The projector can display several resolutions. The following table outlines the resolutions that can be
displayed by the projector.
Signal Resolution
Frequency H.
(KHz)
Frequency V.
(Hz)
Video Digital Analog
NTSC － 15.734 60.0 Ο － －
PAL/SECAM － 15.625 50.0 Ο － －
640 x 350 37.9 85.1 － Ο Ο
720 x 400 31.5 70.0 － Ο Ο
720 x 400 37.9 85.0 － Ο Ο
640 x 480 31.5 60.0 － Ο Ο
640 x 480 37.9 72.8 － Ο Ο
640 x 480 37.5 75.0 － Ο Ο
640 x 480 43.3 85.0 － Ο Ο
800 x 600 37.9 60.3 － Ο Ο
800 x 600 46.9 75.0 － Ο Ο
800 x 600 48.1 72.2 － Ο Ο
800 x 600 53.7 85.1 － Ο Ο
1024 x 768 48.4 60.0 － Ο Ο
1024 x 768 56.5 70.1 － Ο Ο
1024 x 768 60.0 75.0 － Ο Ο
1024 x 768 68.7 85.0 － Ο Ο
1280 x 1024 64.0 60.0 － Ο Ο
VESA
1600 x 1200** 75.0 60.0 － － Ο
640 x 480 35.0 66.7 － Ο Ο
832 x 624 49.7 74.5 － Ο Ο
1024 x 768 60.2 74.9 － Ο Ο
Apple Macintosh
1152 x 870 68.7 75.1 － Ο Ο
480i 31.5 30.0 － － －
576i 31.3 25.0 － － －
SDTV
480p 31.5 60.0 － － －
576p 31.3 50.0 － － －
HDTV 720p 45.0 60.0 － － －
Ο : Frequency supported - : Frequency not supported
The native resolution for the PR5020 and PR3020 is 1024 x 768. The native resolution for the PR3010
is 800 x 600. Resolution other than native mode may be displayed with uneven size of text or lines.
UXGA resolution with half-sampling
Digital Timing is only for PR5020
