DLP® Projector – User’s Manual
– 3 –
I TEM L ABEL D ESCRIPTION S EE PAGE :
8.
Height-adjuster button Push to release height adjuster 16
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
Top view—On-screen Display (OSD) buttons and LEDs
I TEM L ABEL D ESCRIPTION S EE PAGE :
1.
Keystone/
Down cursor Corrects image-trapezoid (wider bottom) effect
Navigates and changes settings in the OSD
18
2.
VOL-/
Left cursor Decreases volume
Navigates and changes settings in the OSD
18
Orange Lamp ready—you can safely turn on or off the projector
3.
Ready LED
Flashing Lamp not ready—do not press the power button
4. Keystone/
UP cursor Corrects image-trapezoid (wider top) effect
Navigates and changes settings in the OSD
18
Green Unit is powered on and working correctly
Off Unit is powered off
5. Power LED
Flashing Operational error code
(refer to “LED Error Messages” on page 38)
6.
Enter Changes settings in the OSD
18
