90
EN
Video decoding
- MPEG-2 DVB compliant up to
MP@ ML
- Video bit rate: up to 15 Mbit/sec
- Video format: 4:3 with options for
1 6:9 broadcast, Pan & Scan, Letter
box, 16:9
- Resolution:
up to 720x576 pixels
Ease of Installation
- Automatic channel installation
- Automatic channel list update
- Up to 1000 channels
- Bouquet auto-installation including
Premiere (network dependant)
Audio decoding
- MPEG layer I / II
- Dolby Digital
- Multi-channel down-mixing
Ease of Use
- Channel list editing for
personalised installation (delete,
add, move)
- Bouquet selection
- Full remote control
- 7 days EPG (network dependant)
- Automatic recording via: Timer
programming in EPG Easy
recording for Philips VCR and
DVD-R
- Now & Next program monitoring
Operation/Features
- TV & Radio modes
- Reception of Pay TV for: Channels
on KDG cable network, Premiere
programmes on private or KDG
cable network.
- Subtitles
- Parental lock with password
- Audio mode: Mono, Stereo
- Menu-controlled installation and
operation
- 8 event Timers/Reminders
- Automatic VCR to TV SCART
bypass for audio L/R + CVBS or
RGB video signals
- Software upgrade via: Cable
network, Serial interface
- Eco mode consumption: <2 W
- Dolby Digital audio output
Application system resources
Processor: 200 MHz
SDRAM - CPU/Video-Graphics: 32 MB
Flash - Data/Code: 4 MB
EEPROM: 8 kB
Reception-Demodulation
- Demodulation :
Type: QAM
Constellation: 16, 32, 64, 128, 256
- Symbol rate range (MS/s):
3 to 6.9
- Channel bandwidth (MHz): 8
- RF input
Frequency range (MHz):
47 to 862
Input level range (dBµV):
44 to 75 in 64 QAM
51 to 75 in 256 QAM
Return loss (dB): ≥ 10
Noise figure (dB): 9.5
- RF loop-through:
Frequency range (MHz):
47 to 862
De-scrambling
Embedded Type: DVB compliant
Smart card reader: 1 for CA
CA system: Nagravision
Note: a subscription is required to
watch Premiere and other Pay TV
programmes.
Connections
- RF connections
input: IEC 169-2 female/75 Ohm
output: IEC 169-2 male/75 Ohm
- TV SCART
Output: CVBS, Controlled audio
L/R, RGB/Fast blanking, Slow
blanking
- VCR SCART
Input: CVBS, Slow blanking, Audio
L/R, RGB/Fast blanking
Output: CVBS, Audio L/R, Slow
blanking during timer if "Prepare
Record" mode is activated
- Audio outputs
L/R output:Volume controlled
analogue audio
Coaxial SPDIF: AC3 or PCM
- Serial interface: hidden (for service
only)
- IR interface
Cinch: for future use
Accessories
- AC/DC power adapter
- Remote control type
RC19336005/01
- Batteries: 2 x 1.5V type AA/R06
- User manual
- Worldwide Guarantee booklet
- SCART lead
- RF coaxial cable
Miscellaneous
- Temperature range (°C)
Operating: +10 to 40
Storage: -25 to +70
- Mains: 230 V ~ +/-10% : 50 Hz
- Maximum power consumption (W):
Running mode: 10
Passive standby: 9
Eco mode: 2
- Weight (Kg): 0.5
Including packaging: 1.2
- Dimensions (mm):
Product: 240x150x45
Packaging: 341 x 245 x 65
Multi-language
- Menu: English, German
- User Manual: English, German
This product complies with the following European Directives: 95/47/EC and 2002/21/EC.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property
rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
Due to continued product improvements, this information is subject to change without notice.
"Dolby" and the double D symbol are trademarks of Dolby Laboratories. Manufactured under license from
Dolby Laboratories.
This product complies
with the following
European Directives:
- 73/23/EEC
- 93/68/EEC
- 89/336/EEC
13 Technical specifications
