There are several ways you can connect and integrate your Digital-Receiver into your
existing audio/video equipment setup.
Warning!
Before starting:
1 Unplug all equipment (TV set as well as VCR and/or DVD) from the mains. Do not
connect your Digital-Receiver to the mains supply now.
2 Check your current wiring because you might keep existing connections of your
current Audio/Video setup.
3 Choose the relevant connection method for incorporating your Digital-Receiver
into your existing audio/video setup
4.1 Connecting to a TV and VCR both fitted
with SCART sockets
Incorporate your receiver in your existing installation as described below.
4 Connecting your
Digital-receiver
to AC outlet
TV set
VCR/DVD
ANT IN
ANT OUT
EXT 1
EXT 2
EXT 1 EXT 2
Cable Receiver
Cable Wall socket Supplied
Supplied
