5
CHARGING BATTERY
1. Open connector cover.
2. Insert connector into left side
(2 gold contacts) of
connector area at bottom
end of the phone. Connect
Travel Charger into mains
power socket.
3. When charging is complete,
remove from mains power
socket and press release
button to disconnect the charger from the phone.
• DO NOT force connector: it may damage phone or Travel
Charger.
Charging Icons on Main and External Display
bars scroll when charging
bars stop scrolling when charging is complete
• If the phone is switched on, Battery full message displays
when charging is complete.
Low Battery Warning
When the battery power is low, Battery low message displays
and a warning tone sounds; phone will automatically switch off.
Fully recharge the battery. If you receive the low battery warning
during a conversation, finish your call immediately.
Note: First verify that battery is installed.
