E‐14 Hardware Reference Manual
www.picocomputing.com
Pico Computing, Inc.
26
ETHER_TX_ER
AA18
MII/GMII TX Error
I
LV_CMOS 2.5V
F\L\A\S\H\_\B\Y\T\E\
AD3
Inverted 8/16 Bit Mode Select
O
LV_CMOS 2.5V
F\L\A\S\H\_\O\E\
AA3
Inverted Output Enable
O
LV_CMOS 2.5V
F\L\A\S\H\_\R\E\S\E\T\
T3
Inverted Reset
O
LV_CMOS 2.5V
F\L\A\S\H\_\W\E\
W5
Inverted Write Enable
O
LV_CMOS 2.5V
F\L\A\S\H\_\W\P\
Y16
InvertedWrite Protect
O
LV_CMOS 2.5V
F\L\A\S\H\_C\E\
V3
Inverted Chip Enable
O
LV_CMOS 2.5V
F\P\G\A\_\P\R\O
K17
Inverted FPGA Program
O
LV_CMOS 2.5V
FLASH_A0
AD6
Address 0 [LSB]
I/O
LV_CMOS 2.5V
FLASH_A1
AD8
Address 1
I/O
LV_CMOS 2.5V
FLASH_A2
AD10
Address 2
I/O
LV_CMOS 2.5V
FLASH_A3
AC11
Address 3
I/O
LV_CMOS 2.5V
FLASH_A4
AD9
Address 4
I/O
LV_CMOS 2.5V
FLASH_A5
Y3
Address 5
I/O
LV_CMOS 2.5V
FLASH_A6
AC9
Address 6
I/O
LV_CMOS 2.5V
FLASH_A7
V4
Address 7
I/O
LV_CMOS 2.5V
FLASH_A8
P3
Address 8
I/O
LV_CMOS 2.5V
FLASH_A9
U5
Address 9
I/O
LV_CMOS 2.5V
FLASH_A10
P5
Address 10
I/O
LV_CMOS 2.5V
FLASH_A11
AC4
Address 11
I/O
LV_CMOS 2.5V
FLASH_A12
N4
Address 12
I/O
LV_CMOS 2.5V
FLASH_A13
R5
Address 13
I/O
LV_CMOS 2.5V
FLASH_A14
W3
Address 14
I/O
LV_CMOS 2.5V
FLASH_A15
AA8
Address 15
I/O
LV_CMOS 2.5V
FLASH_A16
AD4
Address 16
I/O
LV_CMOS 2.5V
FLASH_A17
AD11
Address 17
I/O
LV_CMOS 2.5V
FLASH_A18
AB6
Address 18
I/O
LV_CMOS 2.5V
FLASH_A19
AC7
Address 19
I/O
LV_CMOS 2.5V
FLASH_A20
AC6
Address 20
I/O
LV_CMOS 2.5V
FLASH_A21
AB5
Address 21
I/O
LV_CMOS 2.5V
FLASH_A22
AB11
Address 22
I/O
LV_CMOS 2.5V
FLASH_A23
AB9
Address 23
I/O
LV_CMOS 2.5V
FLASH_A24
AB4
Address 24
I/O
LV_CMOS 2.5V
FLASH_A25
AC3
Address 25 [MSB]
I/O
LV_CMOS 2.5V
FLASH_D0
V12
Data 0 [LSB]
I/O
LV_CMOS 2.5V
FLASH_D1
V13
Data 1
I/O
LV_CMOS 2.5V
FLASH_D2
V14
Data 2
I/O
LV_CMOS 2.5V
FLASH_D3
U14
Data 3
I/O
LV_CMOS 2.5V
FLASH_D4
W13
Data 4
I/O
LV_CMOS 2.5V
FLASH_D5
Y13
Data 5
I/O
LV_CMOS 2.5V
FLASH_D6
W14
Data 6
I/O
LV_CMOS 2.5V
FLASH_D7
W15
Data 7
I/O
LV_CMOS 2.5V
FLASH_D8
V11
Data 8
I/O
LV_CMOS 2.5V
FLASH_D9
W11
Data 9
I/O
LV_CMOS 2.5V
FLASH_D10
U15
Data 10
I/O
LV_CMOS 2.5V
FLASH_D11
U16
Data 11
I/O
LV_CMOS 2.5V
