E‐14 Hardware Reference Manual
www.picocomputing.com
Pico Computing, Inc.
24
CB_CAD15
D6
CardBus Data/Address 15
I/O
LV_TTL 3.3V
CB_CAD16
C7
CardBus Data/Address 16
I/O
LV_TTL 3.3V
CB_CAD17
J5
CardBus Data/Address 17
I/O
LV_TTL 3.3V
CB_CAD18
K6
CardBus Data/Address 18
I/O
LV_TTL 3.3V
CB_CAD19
E5
CardBus Data/Address 19
I/O
LV_TTL 3.3V
CB_CAD20
E6
CardBus Data/Address 20
I/O
LV_TTL 3.3V
CB_CAD21
E7
CardBus Data/Address 21
I/O
LV_TTL 3.3V
CB_CAD22
D9
CardBus Data/Address 22
I/O
LV_TTL 3.3V
CB_CAD23
C8
CardBus Data/Address 23
I/O
LV_TTL 3.3V
CB_CAD24
F10
CardBus Data/Address 24
I/O
LV_TTL 3.3V
CB_CAD25
G4
CardBus Data/Address 25
I/O
LV_TTL 3.3V
CB_CAD26
J3
CardBus Data/Address 26
I/O
LV_TTL 3.3V
CB_CAD27
L10
CardBus Data/Address 27
I/O
LV_TTL 3.3V
CB_CAD28
K8
CardBus Data/Address 28
I/O
LV_TTL 3.3V
CB_CAD29
F4
CardBus Data/Address 29
I/O
LV_TTL 3.3V
CB_CAD30
K11
CardBus Data/Address 30
I/O
LV_TTL 3.3V
CB_CAD31
H9
CardBus Data/Address 31
I/O
LV_TTL 3.3V
CB_CAUDIO
H3
Card Audio Signal
O
LV_TTL 3.3V
CB_CBLOCK
B9
Card Lock
I/O
LV_TTL 3.3V
CB_CC/BE0
H4
Command and Byte Enables
I/O
LV_TTL 3.3V
CB_CC/BE1
C6
Command and Byte Enables
I/O
LV_TTL 3.3V
CB_CC/BE2
H6
Command and Byte Enables
I/O
LV_TTL 3.3V
CB_CC/BE3
D10
Command and Byte Enables
I/O
LV_TTL 3.3V
CB_CCLK
D11
Clock
I
LV_TTL 3.3V
CB_CCLKRUN
G10
Clock Request / Status
I/O
LV_TTL 3.3V
CB_CDEVSEL
G12
Device Select
I/O
LV_TTL 3.3V
CB_CFRAME
H8
Cycle Frame
I/O
LV_TTL 3.3V
CB_CGNT
A9
Grant
I
LV_TTL 3.3V
CB_CINT
B11
Card Interrupt Request
O
LV_TTL 3.3V
CB_CIRDY
G7
Initiator Ready
I/O
LV_TTL 3.3V
CB_CPAR
A7
Parity
I/O
LV_TTL 3.3V
CB_CPERR
A8
Parity Error
I/O
LV_TTL 3.3V
CB_CREQ
B10
Request
O
LV_TTL 3.3V
CB_CRST
D8
Card Reset
I
LV_TTL 3.3V
CB_CSERR
C9
System Error
O
LV_TTL 3.3V
CB_CSTOP
A10
Stop Transaction
I/O
LV_TTL 3.3V
CB_CSTSCHG
J9
Card Status Change
O
LV_TTL 3.3V
CB_CTRDY
E8
Target Ready
I/O
LV_TTL 3.3V
CB_RFU1
E3
CardBus: Reserved for Future Use
I/O
LV_TTL 3.3V
CB_RFU2
H7
CardBus: Reserved for Future Use
I/O
LV_TTL 3.3V
CB_RFU3
B7
CardBus: Reserved for Future Use
I/O
LV_TTL 3.3V
CPLD_TDI
R13
CPLD JTAG TDI
LV_TTL 3.3V
DAC_AMP_PWUP
K12
D/A Amplifier Power Up
O
LV_TTL 3.3V
DAC_CLK
H11
Clock
O
LV_TTL 3.3V
DAC_CLK‐
J11
Complementary Clock
O
LV_TTL 3.3V
DAC_CMODE
B6
Clock Mode Selection
O
LV_TTL 3.3V
