By connecting to the Internet, you can use the following functions:
≥You can obtain the most recent CD title information from the online Gracenote
® database.
[This unit has an abbreviated Gracenote ® database in the HDD. CD title information can be obtained even if you are not
connected to the Internet. ( ➜ page 31, About the Gracenote ® database)].
≥Importing WMA/MP3 data ( ➜ page 40), data backup (➜ page 88), etc., are all functions that use the network. (Functions other
than those listed above are not supported by network services.)
[Note]
≥The name for the terminal may differ depending on the device.
≥Refer to the operating instructions for the connected device.
≥Inserting any cable other than a LAN cable in the LAN terminal can damage the unit.
Optional connections and settings
Network connection
When you have a dedicated Internet connection (such as cable, broadband, etc.), after checking with your Internet Service
Provider (ISP) and the service agreement, make connections and settings using indicated equipment.
For further information about network connection visit the following homepage.
http://panasonic.jp/support/global/cs/audio
R L
XM SPEAKERS
AC IN
DIGITAL
OPTICAL
OUT IN(TV) AV OUT
AM ANT
FM ANT
75
LAN
LOOP ANT GND COMPONENT VIDEO OUT
SUB- WOOFER
(4 )
CENTER
FRONT (8 )
(8 )
VIDEO OUT
R
Y
L
R
L
P R
P B
(10BASE-T/
100BASE-TX)
AUX TV IN
EXT
LOOP TRANSMITTER
DIGITAL
OPTION V.1
DC OUT 5V
500mA MAX
≥When using a modem with broadband router capabilities,
and if there are no open modem ports, connect a hub. If
the modem does not have broadband router capabilities,
connect a broadband router.
≥Use a router that supports 10BASE -T/100BASE -TX.
PC
Telecommunications
equipment (modem, etc.)
Straight LAN cable (not included)
Hub or broadband router
Main unit Internet
