Personal Facsimile
Model No.
KX-PW32CL
Quick Reference Guide for the Portable Hand Scanner
Location of controls
Delete button
Used to delete the
scanned contents
Send button
Used to send the
scanned contents
to the main unit.
Operation indicator
Shows the condition of
the scanner.
Power indicator
· Shows if the power is on / off.
· Shows the amount of battery
power left.
Imaging
sensor
Rollers
Battery compartment
cover
Battery compartment
Infrared connection
window
Used to make infrared
connection with the main unit.
Start / Stop button
Used to start or stop
scanning.
Resolution button
Used when scanning
small letters or
photographs.
Resolution
indicator
Shows the
selected
resolution.
Memory indicator
Shows the amount of
memory being used.
Power button
Used to turn
on / off the power.
Installing the batteries
Battery compartment cover
Imaging sensor
1
2
3
1
Slide open the battery cover by slightly pushing the
part strongly towards yourself.
●
Do not touch the imaging sensor with your fingers.
●
When changing the batteries, turn off the power of the hand scanner
and take out all the old batteries.
2
Place 3 alkaline batteries in the battery
compartment, according to the
indication.
●
Place the batteries in the order of
to
3
Close the battery compartment cover.
