Philips Semiconductors

User’s Manual - Preliminary -

P89LPC901/902/903

WATCHDOG TIMER

2003 Dec 8

85

MOV

WFEED1,#0A5h

; do watchdog feed part 1

MOV

WFEED2,#05Ah

; do watchdog feed part 2

SETB

EA

; enable interrupt

In timer mode (WDTE = 0), WDCON is loaded to the control register every CCLK cycle (no feed sequence is required to load the
control register), but a feed sequence is required to load from the WDL SFR to the 8-bit down counter before a time-out occurs.

Figure 12-2: Watchdog Timer Control Register

The number of watchdog clocks before timing out is calculated by the following equations:

tclks = (2

(5+PRE)

)(WDL+1)+1

where:

• PRE is the value of prescaler (PRE2-PRE0) which can be the range 0-7, and;
• WDL is the value of watchdog load register which can be the range of 0-255.
The minimum number of tclks is:

tclks = (2

(5+0)

)(0+1)+1 = 33

The maximum number of tclks is:

tclks = (2

(5+7)

)(255+1)+1 = 1,048,577

The following table shows sample P89LPC901/902/903 timeout values.

WDCON
Address: A7h

Not bit addressable
Reset Source(s): See reset value below
Reset Value:

111xx1?1B

(Note: WDCON.7,6,5,2,0 - set to ’1’ any reset; WDCON.1 - cleared to ’0’ on Power-on
reset, set to ’1’ on watchdog reset, not affected by any other reset)

BIT

SYMBOL

FUNCTION

WDCON.7-5

PRE2-PRE0

Clock Prescaler Tap Select. Refer to Table for details.

WDCON.4-3

-

Reserved for future use. Should not be set to 1 by user program.

WDCON.2

WDRUN

Watchdog Run Control. The watchdog timer is started when WDRUN = 1 and stopped
when WDRUN = 0. This bit is forced to 1 (watchdog running) and cannot be cleared if both
WDTE and WDSE are set to 1.

WDCON.1

WDTOF

Watchdog Timer Time-Out Flag. This bit is set when the 8-bit down counter underflows.
In watchdog mode, a feed sequence will clear this bit. It can also be cleared by writing ’0’
to this bit in software.

WDCON.0

WDCLK

Watchdog input clock select. When set, the watchdog oscillator is selected. When cleared,
PCLK is selected. (If the CPU is powered down, the watchdog is disabled if WDCLK = 0,
see section "Power down operation"). (Note: If both WDTE and WDSE are set to 1, this
bit is forced to 1.) Refer to section "Watchdog Clock Source" for details.

7

6

5

4

3

2

1

0

PRE2

PRE1

PRE0

-

-

WDRUN WDTOF WDCLK
