Service and repair should be performed only by Lincoln Electric factory trained personnel.
Unauthorized repairs performed on this equipment could result in danger to the technician or the
machine operator and will invalidate your factory warranty. For your safety and to avoid electrical
shock, please observe all safety notes and precautions detailed throughout this manual.

If for any reason you do not understand the test procedures or are unable to perform the
tests/repairs safely, contact the Lincoln Electric Service Department for technical troubleshooting
assistance before you proceed. Call (800) 833-9353 (WELD).

TEST DESCRIPTION

This test will determine if the correct voltage is being induced on the secondary winding of the
control transformer.

MATERIALS NEEDED

Volt/Ohm Meter (Multimeter)
MULTI-SOURCE wiring diagrams (See Electrical Diagram Section of Manual).
3/8” Nut Driver

WARNING

TROUBLESHOOTING & REPAIR

This procedure takes approximately 30 minutes to perform.
