Service Notification Cycles
When the water heater control determines that a scheduled
service is due based on the number of water heater cycles, the
water heater display will alternate the standard water heater
display text with the message SERVICE DUE every 5 seconds.
This parameter is adjustable by the installer by accessing
parameter I3. The range for this parameter is 0 cycles to
100,000 cycles. The default is 50,000 cycles.
Reset Maintenance Reminder
Once servicing has been completed, the service notification
counter should be reset. This parameter can be reset by the
installer by accessing parameter I4. Once accessed, press the
RESET key to reset the service notification counter.
Installer Name and Phone Number
When a Maintenance Reminder timer or counter has expired,
a Maintenance Reminder screen will appear on the display.
By programming the installer’s name and phone number, this
information will appear on the Maintenance Reminder
Screen at that time. This can be programmed by accessing
parameter I5. When selected, another menu will appear with
PHONE and NAME.
1. Rotate the NAVIGATION dial to point to the
name/phone number to program and press the
NAVIGATION dial. The screen will now display the
selected item (either PHONE or NAME).
2. Press the NAVIGATION dial again. A cursor will
appear at the bottom of the screen. By rotating the
NAVIGATION dial, various numbers and characters
will appear. When the desired number/character is
found, press the NAVIGATION dial. The cursor will
move to the next position.
3. Repeat this procedure until the entire message is
entered. If you make a mistake and wish to back up
one character, select the back arrow (
←) character and
press the NAVIGATION dial.
4. When finished, press the RIGHT SELECT [SAVE] key
to return to the previous menu.
Please note that the brackets ([]) denote
screen status.
NOTICE
Set Point at Maximum Volts
When programmed for BMS control through the 0 - 10V
BMS input or through ModBus and the BMS Type is
programmed as SETPOINT, the set point represented by the
Volts at Maximum parameter (H4) is set by parameter H7.
The minimum value is the Set Point at Minimum Volts
setting H6 and the maximum is 190°F (88°C). The default
value is 180°F (82°C).
On Volts
When programmed for BMS control through the 0 - 10V
BMS input or through ModBus and the BMS Thermostat
Input is set to INACTIVE, parameter H8 determines the 0 -
10V BMS input voltage at which the water heater is enabled.
The minimum value is 0.5V and the maximum is 10.0V. The
default value is 2.0V.
Off Differential Volts
When programmed for BMS control through the 0 - 10V
BMS input or through ModBus and the BMS Thermostat
Input is set to INACTIVE, parameter H9 determines how far
below the On Volts setting H8 the 0 - 10V BMS input voltage
must be in order to disable the water heater. The minimum
value is 0.2V and the maximum is the On Volts setting H8.
The default value is 1.0V.
I: Service Notification
Service Notification in Months
When the water heater control determines that a scheduled
service is due based on days of installation, the water heater
display will alternate the standard water heater display text
with the message SERVICE DUE every 5 seconds. This
parameter is adjustable by the installer by accessing
parameter I1. The time range for this parameter is 0 months
to 36 months. The default time is 0 months.
This feature has been disabled by the manufacturer. To
enable this feature change parameter I1 to the desired time
range.
Service Notification Running Time
When the water heater control determines that a scheduled
service is due based on the hours of actual operation, the
water heater display will turn yellow and a new status screen
will appear informing the installer that maintenance is
required. This parameter is adjustable by the installer by
accessing parameter I2. The time range for this parameter is
0 hours to 100,000 hours. The default time is 8,760 hours.
