Managing Intelligent Multicasting (Layer 2 & Layer 3)
15
-18
Cajun P550/P220 Switch Operation Guide
4. Click...
•
CLEAR to reset selected row information.
•
CLEAR ALL to reset all statistics.
•
REFRESH to view the latest information.
Configuring/Viewing CGMP Snooping
To configure CGMP snooping and view its statistics:
1. In the Intelligent Multicasting section of the Web Agent window, click CGMP
Snooping. The CGMP Snooping dialog box opens.
Note: You must enable intelligent multicasting on a global basis to make CGMP
snooping configuration active.
2. Use Table 15-13 for more information on CGMP snooping parameters.
Table 15-13. CGMP Snooping Parameters
Parameter
Definition
Enable State
Select to enable or disable CGMP snooping.
CGMP Packet
Reception Statistics
•
Join Messages Received - Displays the number of
CGMP join messages received.
•
Leave Messages Received - Displays the number of
CGMP leave messages received.
•
Unknown Messages Received - Displays the
number of unknown CGMP messages received.
Intelligent Multicast
Session Statistics
•
New Sessions Created - Displays the number of new
multicast sessions created by CGMP snooping.
•
New Client Ports Added - Displays the number of
new client ports added to a multicast session by CGMP
snooping.
•
Existing Sessions Removed - Displays the number of
existing multicast sessions that have been removed by
CGMP snooping.
•
All Sessions Removed - Displays the number of
times that all multicast sessions created by CGMP
snooping were removed.
•
New Router Ports Added - Displays the number of
new router ports added by CGMP snooping.
•
Existing Router Ports Removed - Displays the
number of router ports that were created by the CGMP
snooper and were then removed by CGMP snooping.
