Managing Intelligent Multicasting (Layer 2 & Layer 3)
Cajun P550/P220 Switch Operation Guide 15 -17
Modifying LGMP Clients Per VLAN
To modify LGMP clients per VLAN:
1. In the Intelligent Multicasting section of the Web Agent window, click LGMP
Client. The LGMP Client Configuration dialog box opens.
Note: You must enable intelligent multicasting on a global basis to make your LGMP
client per VLAN configuration active.
2. In the LGMP Clients column, click the number. The LGMP Client Display per
VLAN dialog box opens.
3. Use Table 15-12 for more information on clients per VLAN parameters.
Table 15-12. LGMP Client Display per VLAN Parameters
Parameter Definition
Select Select the LGMP client to modify.
VLAN Displays the VLAN associated with the LGMP client.
LGMP Message
Reception Statistics • Report - Displays the number of LGMP report
messages received per VLAN.
• Leave - Displays the number of LGMP leave messages
received per VLAN.
• End Session - Displays the number of LGMP end
session messages received per VLAN.
• Router Report - Displays the number of LGMP router
report messages received per VLAN.
• Router Leave - Displays the number of LGMP router
leaves messages received per VLAN.
• Invalid - Displays the number of LGMP messages
received with an invalid payload per VLAN.
Intelligent Multicast
Session Statistics • New Client Ports Added - Displays the number of
new clients added by LGMP per VLAN.
• Existing Client Ports Removed - Displays the
number of clients removed by LGMP per VLAN.
• Existing Sessions Removed - Displays the number of
sessions removed by LGMP per VLAN.
• New Router Ports Added - Displays the number of
new routers added by LGMP per VLAN.
• Existing Router Ports Removed - Displays the
number of new routers removed by LGMP per VLAN.
