Configuring the OSPF Routing Protocol (Layer 3)
9 -10 Cajun P550/P220 Switch Operation Guide
Displaying OSPF Links
The OSPF link display provides information on the currently active OSPF links.
To display OSPF links:
1. In the OSPF Display section of the Web Agent window, click Links. The OSPF
Links dialog box opens.
2. Use Table 9-7 review the OSPF link parameters:
Displaying OSPF Neighbors
The OSPF neighbors table summarizes the list of current OSPF interfaces and their
associated neighbors.
To display the OSPF neighbors:
1. In the OSPF Display section of the Web Agent window, click Neighbors. The
OSPF Neighbors dialog box opens.
Table 9-7. OSPF Link Parameters
Parameter Displays the...
State State of the OSPF link.
IP Address IP address of the OSPF link.
Area ID Area ID (IP address) associated with the OSPF link.
Type Type of OSPF link.
DR Router ID Router ID of the designated router.
DR Address IP address of the designated router.
BDR Address IP address of the designated border router.
