MANUAL GEARBOX
DISMANTLE
Bell housing
-
four cylinder engine
1. Remove transfer box, drain and clean
exterior.
2. If fitted, clutch release bearing clip.
3. Remove clutch release assembly.
4. Remove one pivot post bolt, slacken the other
and move post aside.
Remove six bolts and withdraw bell housing.
GEAR SELECTOR HOUSING
1. Remove four bolts and remove main gearbox
selector housing.
2. Remove transfer box housing.
Remove remaining bolts and remove remote
housing.
Bell housing
-
V8 engine
Remove clutch release bearing.
2. Remove screw and spring clip and remove
release lever.
Remove
"C" clip from pivot post.
4. Remove six bolts and bell housing.
