Perform the, Input rectifier test, Troubleshooting & repair – Lincoln Electric INVERTEC V250-S User Manual
Page 47: Test description, Materials needed, Warning
F-15
TROUBLESHOOTING & REPAIR
F-15
INVERTEC V250-S
TEST DESCRIPTION
This test will help determine if the input rectifier has “shorted” or “open” diodes.
MATERIALS NEEDED
Analog voltmeter/ohmmeter (Multimeter)
Phillips head screwdriver
Wiring diagram
INPUT RECTIFIER TEST
Service and repair should be performed only by Lincoln Electric factory trained per-
sonnel. Unauthorized repairs performed on this equipment could result in danger to
the technician or the machine operator and will invalidate your factory warranty. For
your safety and to avoid electrical shock, please observe all safety notes and precau-
tions detailed throughout this manual.
If for any reason you do not understand the test procedures or are unable to perform
the tests/repairs safely, contact the Lincoln Electric service department for technical
troubleshooting assistance before you proceed.
Call (216) 383-2531 or (800) 833-9353 (WELD).
_____________________________________________________________
WARNING
