F-77 TROUBLESHOOTING & REPAIR F-77
RETEST AFTER REPAIR
INVERTEC V250-S
Should a machine under test be rejected for any reason requiring the removal of any mechanical part that could
affect the machine’s electrical characteristics, or if any electrical components are repaired or replaced, the
machine must be retested.
INPUT IDLE AMPS AND IDLE WATTS
MAXIMUM ACCEPTABLE OUTPUT (AT MINIMUM OUTPUT SETTINGS)
MINIMUM ACCEPTABLE OUTPUT (AT MAXIMUM OUTPUT SETTINGS)
OPEN CIRCUIT VOLTAGE RANGE
INPUT CURRENT @ IDLE LESS THAN 2 AMPS
INPUT POWER @ IDLE LESS THAN 200 WATTS
MODE AMPS VOLTS
All 1 Amp 10 VDC.
MODE AMPS VOLTS
All 250 Amps 33 VDC.
MODE VOLTS
All 65 - 80 VDC.
