Danish Interpretation Systems

User Manual

Manual 01 18 04438

38

Technical specifications

Digital Section

Sound quality .........24 bit audio @ 32 kHz sampling frequency

Analogue Section

Floor output signal type ......................... electronically balanced

Nominal output level .......................... -8 dBm at nominal input

Max. output level .................................... 3.5V RMS

+13 dBm

Line input signal type ............................ electronically balanced

Nominal input level (adjustable).................................................

...............................+6 to -30 dBm (1.55 V RMS to 25 V RMS)

Max. input level ...................................... +30 dBm (25V RMS)

Line input impedance ..............................................25-50 kohm

Frequency response .................................................... 50-15kHz

Signal to noise ratio: .................................................. >85 dBA

Total harmonic distortion: ............................................ < 0.1%

General

Power consumption .............................. max. 150W (CU 6005)

.......................................................max. 600W (CU 6010/6011)

In-rush current ...............max. 30A@115V or max. 60A@230V

Mains voltage: ....................................... 100 - 240V, 50 - 60Hz

Supply voltage for units..............................................................

(for: A1 plus A2) .................................... 48V/125W (CU 6005)

(for each: A1, A2, B1, B2)............. 48V/125W (CU 6010/6011)

Temperature to guarantee specified performance

..............................5 Deg C. to 40 Deg C. (35 to 80% humidity)

Storage temp. .... -20 Deg C. to 60 Deg C. (10 to 80% humidity)

Weight ............................................................ 5.7 kg (CU 6005)

............................................................... 6.2 kg (CU 6010/6011)

Dimensions (W x H x D) .......... 425 (483) x 87 x 317 (357) mm

Dimensions in bracket are including 19” brackets

Slot dimensions (W x H x D)..... 180 x 38 x 120 mm (CU 6005)

Accessories supplied............................................... User manual

.................................................................................Mains cable

.......................................................... 5 pieces termination plugs

Connectors

DCS 6000 network chain (DCS-LAN)............................... RJ45

.....................................................................2 pieces (CU 6005)

............................................................4 pieces (CU 6010/6011)

Maximum number of units to be connected to the two
outputs in total on a CU 6005 or to each chain of the four
outputs on a CU 6010/6011:

MU 6040 Microphone Units ...................... up to 80 pieces

DM/CM 60x0P Delegate/Chairman Unit ...up to 42 pieces

IS 6132P Interpreter Set ..............................up to 54 pieces

CS 6032F Channel Selector .....................up to 110 pieces

The actual maximum number of units depends on the
length of the feeding cable and interconnection cables

Line output .............................................. XLR3 male connector

Line input ............................................. XLR3 female connector

RS 232 (with hardware handshake)....................D-Sub 9 female

RS 422 (with hardware handshake ........................D-Sub 9 male

................................either the RS232 or the RS422 can be used

System performance with CU
6005/6010/6011 as central unit

Max. number of conference units ............3800 (CU 6010/6011)

Max. number of conference units .......................500 (CU 6005)

Max. number of units (excl. CS) .........................................4000

Max. number of IS 6xxx in one booth.................................... 32

Max. number of IS 6xxx ...................................................... 150

Max. number of AO 6004/6008 ............................................. 20

Max. number of CS 6032 ...........................practically unlimited

Max. number of languages ................................... 16 (CU 6005)

.................................................................... 31 (CU 6010/6011)

Max number of open microphones........................................... 8

The DCS 6000 system conforms to all relevant standards -
e.g. IEC 914, ISO 4043, and ISO 2603

Specifications are subject to change without notice.
