Danish Interpretation Systems

User Manual

Manual 01 18 04438

30

Typical schematics

The following schematics are showing various configurations:

Small conference microphone system with CU 6005

Small conference microphone system with CU 6010

This manual is related to the following products:

Central Unit CU 6005 Central Unit CU 6011
