User Controls, indications & connectors
Front plate layout
Identical to the CU 6010 Central Unit.
Front plate controls
Identical to the CU 6010 Central Unit.
Back Panel Layout
Back Panel Connectors
As the CU 6010 Central Unit with the following
differences:
Chain A1 & A2 (no chain B1 & B2)
RJ45 connector, 2 pieces
DCS-LAN connectors for connection to DM/CM
6xxx, IS 6132, CS 6032, EX 6010, AO 6004/6008
etc. For connecting Interpreter Sets for up to 16
languages.
Other
Slot (extra)
Slot for inserting modules in the back panel, e.g.
AO 6004. Slot dimensions (W x H x D) 180 x 38 x
120 mm.
System settings
The same as for the CU 6010 Central Unit.
Normal Operation
The same as for the CU 6010 Central Unit.
