INSTALLATION

A-10

POWER FEED® 25M

TYPICAL SYSTEM CONFIGURATIONS

Standard Features

Arc Performance

• Push-Pull ready for welding aluminum with Pulse

and Pulse-on-Pulse™ waveforms.

• STT™ capable when used with STT™ equipped

Power Waves.

• Waveform Control Technology™ for welds with good

appearance and low spatter, even when welding
nickel alloys.

User Interface

• 6 memories for easily selecting procedures.

• MSP4 panel located behind the memory panel door

for protection.

• Full sequence control for tailoring the weld from start

to end.

• All welding controls located at the wire feeder, includ-

ing process selection.

Wire Drive

Patented 2 roll drive system. MAXTRAC™ technology
delivers great feeding because:

• Patent pending drive rolls improve traction on solid

wire by up to 20%.

• The precision machined, rigid aluminum alloy frame

results in maximum drive roll clamping pressure.

• Patented split wire guides fully support the wire and

virtually eliminate birdnesting.

• No tools required to change the drive rolls and wire

guides.

• Patented dual spring pressure arms have sensitivity

for feeding soft wires without crushing them, and
have plenty of compression force for feeding solid or
stiff wires.

• All gear driven rolls for more feeding force.

• Changeable gun bushings easily accept guns from

other manufacturers.

• Brass-to-brass connections between the electrode

connection and the gun minimize voltage drop varia-
tions, resulting in consistent arc performance all day,
every day.

• Powerful, quiet motor with integrated tachometer for

accurate WFS regulation.

Extras

• Flowmeter with gas control valve

• Push-Pull ready.

• Remote control / Foot amptrol ready.

• Internal heater for keeping condensation off of the

spool of wire.

• Internal lights for illuminating the wire drive compart-

ment.

Options

• Water cooling kit for use with water cooled guns.
