Connections & setup, Antenna connection – LG 26LC2R User Manual
Page 20
18
ANTENNA CONNECTION
CONNECTIONS & SETUP
CONNECTIONS
&
SETUP
■
To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.
■
For optimum picture quality, adjust antenna direction.
■
An antenna cable and converter are not supplied.
■
In poor signal areas, to get better picture quality, install a signal amplifier to the antenna as shown to
the right.
■
If signal needs to be split for two TVs, use an antenna signal splitter for connection.
S
Siig
gn
na
all
A
Am
mp
plliiffiie
err
UHF
VHF
ANTENNA
IN
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor Antenna
Wall Antenna Socket
VHF Antenna
UHF Antenna
RF Coaxial Wire (75 ohm)
Turn clockwise to tighten.
ANTENNA
IN
ANTENNA
IN
ANTENNA
IN
ANTENNA
IN
0323G_1-en_rev01 2/28/06 4:12 PM Page 18
