CONNECTIONS
&
SETUP
23
REMOTE
CONTROL IN
AUDIO IN
(RGB)
RGB IN RGB IN
(PC/DTV) (PC/DTV)
RS-232C IN
(CONTR (CONTROL OL & SER SERVICE) VICE)
AUDIO OUT
VARIABLE ARIABLE
HDMI IN HDMI IN
( )
AUDIO VIDEO S-VIDEO
AV IN 3
VIDEO AUDIO
COMPONENT IN
HDMI-DVD OUTPUT
D D V V D D
1 1
When connecting with a HDMI cable
Connect the HDMI output of the DVD to the H HD DM MII IIN N
jack on the set.
Select HDMI input source with using the II N N P P U U T T button
on the remote control.
Refer to the DVD player's manual for operating instruc-
tions.
1
2
3
NOTE !
G G TV can receive the video and audio signal simultaneously with using a HDMI cable.
G G If the DVD supports Auto HDMI function, the DVD output resolution will be automatically set to
1280x720p.
G G If the DVD does not support Auto HDMI, you need to set the output resolution appropriately. To get the
best picture quality, adjust the output resolution of the DVD to 1280x720p.
