8. Wait a minimum of 15 minutes for the Check
Switch function to complete and for the antenna to
restart and configure itself for DISH 500 mode.
If the Check Switch function fails (the receiver locks
up), disconnect power from the receiver, restart the
antenna, then restore power to the receiver and try the
Check Switch function again.
9. Run the Check Switch function a second time. This
allows the receiver to configure itself for automatic
satellite switching.
10. Wait until the Check Switch function is complete
(it will take a couple minutes).
11. Ensure that the following is displayed on the TV:
This indicates that the receiver is configured
properly. If this information is not displayed
exactly
as shown above, try running the Check
Switch function again.
12. Exit the menu and allow the receiver to download
the program guide.
13. Once the program guide has loaded, you can start
enjoying satellite TV. The antenna will now switch
between satellites automatically as you change
channels using the receiver’s remote control.
3-9
Using Your TracVision R5/R4
54-0157 Rev. H
Installed Switch: SW42
Input: 1 1 2 2
Satellite: 119 119 110 110
Polarity: Odd Even Odd Even
Status: Satellite reception verified
Figure 3-6
Check Switch Screen
