1.3
Materials Provided with
TracVision R5/R4
Table 1-3 lists the units, cables, and materials packed in the
TracVision R5/R4 package by name and KVH part number.
Component
KVH Part No.
Antenna Unit (TracVision R5), comprising:
01-0225-19
†
01-0225-22
††
01-0225-25
†††
01-0225-28
††††
Baseplate Assembly (TracVision R5)
02-1245-01
*
02-1245-03
**
Radome Assembly (TracVision R5)
02-0953-03
Antenna Unit (TracVision R4), comprising:
01-0225-21
†
01-0225-27
†††
01-0225-30
††††
01-0225-24
††
Baseplate Assembly (TracVision R4)
02-1245-02*
02-1245-04**
Radome Assembly (TracVision R4)
02-0953-05
RF Cable (28 ft/8.5 m)
32-0417-28
Data/Power Cable (28 ft/8.5 m)
32-0730-28
PC Cable (6 ft/1.8 m)
32-0628-06
Kitpack***
72-0101
Owner’s Manual
54-0157
Receiver Ground Wire
32-0583-50
Switchplate
02-1023-01
TV/SAT Switch (optional)
01-0245
†
European TracVision R5/R4 system
††
North American TracVision R5/R4 system (set to DIRECTV)
†††
North American TracVision R5/R4 system (set to DISH Network)
††††
North American TracVision R5/R4 system (set to ExpressVu)
* Baseplate assembly with single-output LNB
** Baseplate assembly with dual-output LNB
*** A complete listing of kitpack contents is provided in Table 2-2.
1-4
A Guide to TracVision R5/R4
Table 1-3
TracVision R5/R4 Packing List
Cables for the TracVision R5/R4 are
stored beneath the antenna unit
during shipping.
