A-61555 March 2007 5-11
Cleaning the imaging
guides — thorough
cleaning Thorough cleaning of the imaging guides is recommended at the start
of the day and beginning of each shift.
NOTE: Hold the imaging guides at the green tabs to avoid getting
fingerprints on the imaging guides during the cleaning
procedure.
Upper imaging guide
1. Open the pod.
2. Turn the screw on each end of the upper imaging guide and remove
it from its position.
3. Clean the imaging guide thoroughly with a Staticide wipe.
4. Wipe the imaging guide again with an almost-dry Staticide wipe to
remove any streaks.
IMPORTANT: There is no cover glass between the upper lamps. Do not
insert any objects into the area between the upper lamps,
as you may damage the reflective mirrors in the scan
module.
5. Reinstall the upper imaging guide.
