PARTS LIST
NOTE:Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model.However,the method of assembly remains the same.
464220110 • 11
If you are missing hardware or have damaged parts
after unpacking grill, call 1-800-2
41-7548 for
replacement.
To order replacement parts after using grill, call
® 1-800-4-MY-HOME .
Key Qty Description Part#
1 1 LEFT LEG ASSEMBLY G550-0700-W1
2 1 MATCH HOLDER G401-0079-W1
3 1 RIGHT LEG ASSEMBLY G550-1000-W1
4 1 BOTTOM SHELF G550-0800-W1
5 1 FRONT PANEL G550-0900-W1
6 2 TANK EXCLUSION WIRE G550-0004-W1
7 1 AXLE ROD G550-0009-W1
8 2 WHEEL G401-0058-W1
9 2 LEG EXTENDER G430-0023-W1
10 1 TOP LID G550-0100-W1
11 1 LOGO PLATE G528-0002-W2
12 1 TEMPERATURE GAUGE G430-0022-W1
13 1 BEZEL, F/ TEMPERATURE GAUGE G404-0034-W1
14 1 HANDLE F/ TOP LID G550-0001-W1
15 2 SILICONE RUBBER BUMPER,
F/ MAIN LID
G430-00B8-W1
16 2 SILICONE REAR RUBBER BUMPER,
F/ MAIN LID
G303-0038-W1
17 1 TOP LID HARDWARE G430-0024-W1
18 1 FIREBOX G550-0300-W1
19 4 MAIN BURNER TUBE,
NO ELECTRODE
G430-3800-W2
20 1 ELECTRODE, MAIN BURNER G501-0010-W2
21 3 FLAME CARRY OVER TUBE G413-0004-W2
22 1 MAIN CONTROL PANEL G550-0003-W1
23 1 ELECTRONIC IGNITION MODULE G409-0021-W1
24 1 HOSE VALVE REGULATOR G550-5200-W1
25 5 BEZEL, F/ CONTROL KNOB G430-0027-W1
26 5 CONTROL KNOB G432-0010-W1
27 1 RIGHT SIDE SHELF G550-0400-W1
28 1 FASCIA, F/ RIGHT SHELF G550-5301-W1
29 1 SIDEBURNER SHELF G550-0500-W1
30 1 DRIP PAN, F/ SIDEBURNER G430-0034-W2
31 1 SIDEBURNER LID G430-0018-W1
32 1 FASCIA, F/ SIDEBURNER SHELF G550-5401-W1
33 1 SIDEBURNER G550-5600-W1
34 1 ELECTRODE, F/ SIDEBURNER G430-0042-W1
35 1 IGNITOR WIRE, F/ SIDEBURNER G430-5303-W1
36 1 CLIP F/ SIDEBURNER G405-0019-W1
37 1 SIDEBURNER GRID G430-0053-W1
38 1 SHIELD, HEAT, FIREBOX G550-5104-W1
39 4 HEAT DIFFUSER G550-0006-W1
Key Qty Description Part#
40 2 COOKING GRATE G550-0200-W1
41 1 SWING AWAY GRATE G550-0002-W1
42 1 BUTTON, F/ EI MODULE G409-0030-W1
43 1 CLIP, F/ GREASE CUP G305-0043-W1
44 1 GREASE CUP G430-0033-W1
45 1 GREASE TRAY G550-1100-W1
46 1 TANK THUMBSCREW G430-C001-W2
Not Pictured
… 1 PRODUCT MANUAL, ENGLISH G550-010801-W1
… 1 PRODUCT MANUAL, SPANISH G550-010802-W1
… 1 HARDWARE PACK G55001-B001-W1
