Appendices
44
5. Operation of included
Expression pedal
Fortissimo function
This allows you to selectively emphasise parts of your
performance.
As shown in the diagram, the pedal angle is 30° when
fully raised. The pedal will rest at any point you take
your foot off from fully raised to standard position.
If you depress the pedal further from standard position, it
will return to standard position when you take your foot
off.
Also, by adjusting the screw on the bottom, you may
adjust the spring return range from 0°–10 °.
30 °
20 °
0–10 °
Standard position
Spring return range
Range of free
movement
Selectable pedal angle
As shown below, you may change the pedal angle to fit
your plying position.
To select pedal angle
1. Loosen hook screw with a screwdriver.
2. Move the pedal body to the position in the illustra-
tion.
3. Retighten the hook screw.
hook screw
Standing performance Seated performance
hook screw
Cable storage
Store the cable as shown.
