Connecting the Projector
3/99 7
ENGLI
S
H
Connecting to a Desktop Computer
1. Connect the end of the cable hub connector to the
connector on the projector’s connector panel.
2. Locate the cable that connects your monitor to your computer
and unplug it from the computer.
3. Plug your monitor cable into the connector on the cable
hub.
4. Plug the end of the cable hub into the monitor connector
on your computer.
5. Unplug the audio cable, if present, from your computer and
plug either end of the audio cable into the audio connector on
your computer. Plug the other end of the audio cable into the
connector on the cable hub.
audio cable
mouse cable
hub connector
monitor cable
