6.2.1 NX-308 - Related Switch Location (FIGURE 6-3)
To connect the single line telephone to the any station from #2 to #8 of basic
KSU, the related DIP switches should be set as follows.
Station No.
Releated DIP Switches
Setting
STN 2
SW 1
OFF
OFF
ON
ON
STN 3
SW 2
OFF
OFF
ON
ON
STN 4
SW 3
OFF
OFF
ON
ON
STN 5
SW 4
OFF
OFF
ON
ON
STN 6
SW 5
OFF
OFF
ON
ON
STN 7
SW 6
OFF
OFF
ON
ON
STN 8
SW 7
OFF
OFF
ON
ON
6.2.2 NX-820
To connect a single-line telephone to the from #5 to #12 of basic KSU.
6.2.3 NX-1232 - Related Switch Location (FIGURE 6-5)
To connect a single line telephone to any station from #1 to #16 of basic KSU.
Station No.
Releated DIP Switches
Setting
STN 1
SW 8
OFF
OFF
ON
ON
STN 2
SW 7
OFF
OFF
ON
ON
STN 3
SW 6
OFF
OFF
ON
ON
STN 4
SW 5
OFF
OFF
ON
ON
STN 5
SW 4
OFF
OFF
ON
ON
STN 6
SW 3
OFF
OFF
ON
ON
STN 7
SW 2
OFF
OFF
ON
ON
STN 8
SW 1
OFF
OFF
ON
ON
