Faxing
98 www.kodak.com/go/aiosupport
Redial if No Answer Yes (default) / No If the fax number you call does not
answer, the printer will redial the number
automatically one time.
Busy Redial
Attempts 0 to 12
(default is 5)
The number of times that the fax will
attempt to redial a busy number.
Disable Call Waiting No (default) / Yes If you have call-waiting service on your
phone line, you can disable it so that an
incoming call does not interrupt your fax
transmission.
Select Yes to disable call waiting, then
enter the Call-Waiting Disable Code
(below).
NOTE: You must enable call waiting
manually after your fax
transmission.
Call-Waiting Disable
Code *70 (default) The printer automatically dials the
Call-Waiting Disable Code before dialing
the number to which you are sending a
fax. This code disables call waiting for
the duration of the fax, preventing
incoming calls from interrupting your fax
transmission.
The usual code to disable call waiting is
the default *70. If the call waiting disable
code is different in your area, touch
Call-Waiting Disable Code, then touch
the backspace button to erase the
current code. Use the keypad to enter
the correct code, then press
OK.
Distinctive Ring Any ring (default) /
Single Ring / Double
Ring / Triple Ring This service, available from most phone
companies, adds multiple phone
numbers to one phone line. Each phone
number then has a distinctive ring
pattern (single, double, or triple ring) to
let you know which number is ringing.
Select the ring pattern assigned to the
phone number for the printer so the
printer can receive faxes automatically.
Fax Speaker On (default) / Off The fax speaker allows you to hear the
dial tone and initial fax tones when
sending faxes.
Fax Setting Options Description
