Connecting a DVD player (6-channel input)
FRONT
OUT L/R
COAXIAL
DIGITAL
OUT
(AUDIO)
DVD player
SURROUND
OUT L/R
VIDEO OUT
(Yellow RCA
pin cord)
CENTER OUT
SUBWOOFER OUT
If you have connected a DVD player to the receiver with digital connection, be sure to read the "Input mode
settings" section carefully.
7
Be sure to adhere followings or proper ventilation will be blocked causing damage or fire hazard.
• Do not place any objects impairing heat radiation onto the top of unit.
• Leave a space around the unit (from the largest outside dimension including projection) equal or greater than, shown below.
Top panel : 50 cm Side panel : 10 cm Back panel : 10 cm
CAUTION
Setting up the system
To switch the speakers off , press the MUTE key.
