Kenwood TK-3173 User Manual
Page 21
12
r
r
r
r
r LED indicator
Lights red while transmitting. Lights green while receiving
a call. Flashes orange while receiving an encoded
(2-tone, DTMF signaling, etc.) call. If programmed by your
dealer, flashes red when the battery power is low while
transmitting.
t
t
t
t
t Safety Catch
Lock this catch to avoid accidentally pressing the release
latch and removing the battery pack {page 7}.
y
y
y
y
y Release Latch
Press the release latch to unlock and remove the battery
pack {page 7}.
u
u
u
u
u Auxiliary (orange) key
Press to activate its programmable function {page 15}.
i
i
i
i
i PTT (Push-To-Talk) switch
Press this switch, then speak into the microphone to call a
station.
o
o
o
o
o Side 1 key
Press to activate its programmable function {page 15}.
!0
!0
!0
!0
!0 Side 2 key
Press to activate its programmable function {page 15}.
!1
!1
!1
!1
!1 S, A,
Press to activate their programmable functions {page 15}.
!2
!2
!2
!2
!2 DTMF keypad (keypad models only)
Press the keys on the keypad to make DTMF calls
{page 31}.
!3
!3
!3
!3
!3 Speaker/ microphone jacks
Connect an optional speaker/ microphone here {page 10}.
Otherwise, keep the supplied cap in place.
