TECHNICAL DATA - CHASSIS
»
TIGHTENING TORQUES – CHASSIS
Collar bolt on front wheel spindle
M24x1,5 60 Nm
Collar nut wheel spindle rear M25x1,5 90 Nm
AH bolt shock absorber top/bottom M14x1,5 80 Nm
Collar nut for swing arm bolt M19x1,5 130 Nm
AH bolts on subframe M8 Loctite 243 + 25 Nm
AH bolts on back of footrest support M8 Loctite 243 + 25 Nm
Engine carrier bolts M10 45 Nm
HH clamp bolts on top triple clamp M8 20 Nm
HH clamp bolts on bottom triple clamp M8 15 Nm
HH screw for steering head M20x1,5 12 Nm
HH clamp bolts on fork legs M8 15 Nm
Collar bolts for handlebar clamps M8 20 Nm
AH bolt for handlebar mount M10 20 Nm
HH clamp bolts for steering stem M8 20 Nm
Collar bolt front/rear brake disk M8x1,25 Loctite 243 + 30 Nm
HH bolts on front brake caliper M10x1,25 Loctite 243 + 45 Nm
HH bolts on handbrake cylinder M6 10 Nm
HH bolts on footbrake cylinder M6 Loctite 243 + 10 Nm
AH bearing bolt for foot brake pedal, shift lever M8 Loctite 243 + 25 Nm
HH screw on cover plate for foot brake lever/shift mechanism M6 Loctite 243 + 10 Nm
Relay for shift shaft (on connecting support) M8 Loctite 243 + 25 Nm
Relay for shift shaft (on shift shaft) M6 Loctite 243 + 18 Nm
Gearshift rod attachment M6 Loctite 243 + 10 Nm
HH bolts on foot brake pedal surface M5 Loctite 243 + 6 Nm
AH bolts for side stand bracket - engine M10 Loctite 243 + 45 Nm
HH bolts for side stand fixture - side stand bracket M10 Loctite 243 + 25 Nm
HH bolts for side stand mounting M10 Loctite 243 + 35 Nm
HH bolt for spring rest on side stand M8 Loctite 243 + 25 Nm
HH bolt for side stand switch M4 Loctite 243 + 2 Nm
HH nuts on rear sprocket bolts M10x1,25 Loctite 243 + 50 Nm
Drain plug on oil tank M12x1,5 20 Nm
Exhaust nuts on manifold M8 evenly, do not bend sheet metal
Exhaust clamps M8 8 Nm
Exhaust clamps for ball joint M8 35 Nm
AH bolts on tank cover M5 5 Nm
AH/HH bolts on tank mounting M6 6 Nm
Collar screws for in-tank pump M6 6 Nm
AH screw on arm for tank support M10 25 Nm
Collar screw for gas pressure shock absorber M6 6 Nm
Seat fixing plate M5 4 Nm
Jerk damper bolt M10x1,25 Loctite 243 + 50 Nm
HH nut for seat lock M19x1 8 Nm
Chainguard M5 5 Nm
Chain sliding guard M5 5 Nm
Front spoiler M6 Loctite 243 + 10 Nm
Taillight M6 8 Nm
Other bolts on chassis M6
M8
M10
10 Nm
25 Nm
45 Nm
Other collar nuts on chassis M6
M8
M10
15 Nm
30 Nm
50 Nm
