25
EXTERNAL POWER SUPPLIES (SOLD SEPARATELY)
The AC Adapter allows the camera to be powered from an electrical household outlet.
The AC Adapter is recommended when the camera is interfaced with a computer or
during periods of heavy use. AC Adapter model AC-1L is for use in North America and
Japan, and AC-11 is for use in all other areas.
The External High-power Battery Pack Kit EBP-100 is a portable power source and
significantly extends the operating time of the camera. The kit contains a high-power
lithium-ion battery, holder, and charger. The battery, holder, and charger are also
available separately.
Remove the DC terminal cover from the right
(1). The cover is attached to the body to
prevent loss.
Insert the mini plug of the AC adapter or
battery pack into the DC terminal (2).
Insert the AC adapter plug into an electrical
outlet.
Always turn off the camera and confirm the access lamp is not
lit before changing between power supplies.
1
2
