* This camera is a sophisticated optical instrument. Care should be taken to keep these
surfaces clean. Please read the care and storage instructions in the back of this manual
(p. 168).
14 N AMES OF PARTS
CAMERA BODY
Data panel (p. 17)
Front control dial
Shutter-release button
Focusing ring (p. 46)
Focal-length index
Zooming ring
Lens*
Card-slot door (p. 26)
Self-timer lamp (p. 68)
Built-in flash (p. 36)
Strap eyelet (p. 20)
Microphone
NAMES OF PARTS
The focal-length scale on the zooming ring is given in 35mm focal-length equivalents. The
DiMAGE Viewer software supplied with the camera can display the actual focal length used
to capture the recorded image as well as the equivalent focal length in 35mm photography.
Camera Notes
USB port/AV-out
terminal (p. 128, 147)
Gip sensor
