30
Pin assignment of microphone socket
Audio sensitivity
The transmitter’s audio sensitivity can be adjusted over a range of 70 dB
(+4 0 dB to –30 dB) in steps of 1 dB. The diagram bel ow shows the
sensitivity range of the SK 5212 in comparison to the earlier product
generations SK 50 and SK 5012.
A F so cke t
P in 1: +5.2 V fo r exte rna l special micropho nes
P in 2: AF and 5.2 V A B-po wering; 8.2 k
Ω int ernal resist ance,
optimized fo r Sennheiser pre-polarize d
co ndenser micro pho nes
P in 3 a nd thread: gro und
1 2
3
40
24
42
16
1
6
12
18
24
30
36
8
8
16
30
SK 50 SK 5012 SK 5212
0...42 dB
–16...+24 dB
–30...+40 dB
Switch position
