Specifications
Modulation wideband FM
Frequency range 450 – 960 M Hz
Switching bandwidth 36 MHz
Transmission frequencies channel bank “FIX”
with customer-specific frequencies;
channel bank “VAR”
with 20 freely selectable frequencies
(frequencies tunable in steps of 5 kHz)
RF output po wer switchable, typ.: 50 mW (PW R.HI)
10 mW (PW R.LO)
Frequency stability ±10 ppm
Spurious emissio n < 4 nW
Nominal/peak deviation ±40 kHz/±56 kHz
Signa l-to-noise ratio 110 dB(A)
r ms
THD <
0.3 % at nominal deviation, 1 kHz
AF frequency response 60–20,000 Hz
Noise reduction system Sennheiser HiDyn plus™
Input sensitivity at
nominal deviatio n, 1 kHz
–40 dB
u
= 7.75 mV, adjustable in steps
of 1 dB, range: 70 dB
Lo w-cut frequency (–3 dB) adjustable (flat, 120 Hz)
Power supply 1 AA size battery (1.5 V)
Power consumption
(without LC display illumination) appro x. 160 mA at 1.2 V ( PWR.LO)
appro x. 250 mA at 1.2 V ( PWR.HI)
Operating time appro x. 11 hrs (PWR.LO)
appro x. 5.5 hrs ( PWR.HI)
Temperature range –10 °C to +55 °C
Connections AF: 3-pin special microphone socket
RF: coax socket
Dimensions [mm] appro x. 53 x 60 x 17
Weight appro x. 120 g incl. battery
Type approval USA: FCC-Part 74.861
FCC ID: DM OS K5212
Canada: RSS-123, IC: 2099A-SK5212
EU: requirements of R&TTE
EN 50392
ETSI EN 300 422-1/-2, class II
ETSI EN 301 489-1/-9
CE 0682!
