Star Micronics SP300 - Manual (Page 31)

– 27 –
5-2. Printing Format
Prints one line in 7
×
9 font normal printing.
32 columns (from the 5th to 36th columns)
Even if the setting for the paper width is changed by the DIP switch, the 32-
column format will not change.
5-3. Data format
5-4. Other
•
The FEED and ON LINE switches will not operate normally during validation
printing.
•
When the printer receives an immediate execution command for peripheral
units during validation printing, it executes the command when the validation
print mode is canceled.
•
Modes in effect before the validation printing (such as emphasized printing,
inverted printing, expanded printing, and underlining) are invalid during
validation printing. But these become valid again after validation printing.
•
Data received before a code is printed out when the printer receives the
code.
Fig. 5-3 Print area
Paper sensor
position
Print area
52.8
100
Min. 120
Approx.
17
Approx.12
: m m
Approx. 18
Min. 70
