56
MVDS X-1 User's Guide
Name Details
Video
Configuration
H.Position Offset
Displays the offset value for H.Position setting that you may
have configured from LCD menu.
This value is added to H.Position setting and then take effect
in the video image.
H.Width Offset
Displays the offset value for H.Width setting that you may
have configured from LCD menu.
This value is added to H.Width setting and then take effect
in the video image.
H.Period Offset
Displays the offset value for H.Period setting that you may
have configured from LCD menu.
This value is added to H.Period setting and then take effect
in the video image.
V.Position Offset
Displays the offset value for V.Position setting that you may
have configured from LCD menu.
This value is added to V.Position setting and then take effect
in the video image.
V.Width Offset
Displays the offset value for V.Width setting that you may
have configured from LCD menu.
This value is added to V.Width setting and then take effect in
the video image.
V.Period Offset
Displays the offset value for V.Period setting that you may
have configured from LCD menu.
This value is added to V.Period setting and then take effect
in the video image.
Serial
Configuration
Baudrate (bps) Specify a baudrate.
Bit length Specify a bit length.
Stop bit Specify a stop bit.
Parity Specify a parity check method.
Flow control Specify a flow control method.
Data timeout Specify a serial input timeout by millisecond.
Buffer Buffer Level Specify the number of buffer for retransmission.
