MVDS X-1 User's Guide
2.3.1 Connect to a wired network
2.3 Hardware installation
Ethernet HUB
Transmitter
LAN Cable
LAN Cable
LAN Cable
LAN Cable
LAN Cable
Player
Receiver
Display
Receiver
Display
Receiver
Display
Receiver
Display
Sample connection for wired network
To configure this product in a wired network, connect the transmitter and
receivers via Ethernet HUB.
